Heavy Hammer Crusher

Heavy Hammer Crusher Advantages

• Large feed particle size and high output
  The feed particle size of the hammer crusher can reach 1200 mm, and the output of a single hammer crusher can reach 1200 tons.
  The design of the crushing chamber conforms to the dynamic principle. The unique sieve plate-less structure increases the material throughput, can crush wet materials, and solves the problems of straightforward blockage and low output of traditional hammers.
• Low energy consumption and low investment
  The heavy hammer crusher has a large feed particle size and a small discharge particle size. The one-time molding system ultimately realizes low-cost operation.
• Environmentally friendly and less polluting
  It can crush wet materials. Add water when crushing wet materials to reduce dust pollution and protect workers’ health and the environment.
• Excellent finished product particle size
  The material can be adjusted according to needs to meet various specifications.

Heavy Hammer Crusher Structure
The rotor of the hammer crusher consists of a main shaft, a disc, a pin and a hammer.

Heavy Hammer Crusher Working Principle
The motor drives the rotor to rotate in the crushing chamber at high speed. The material is fed into the machine from the upper feeding port and crushed by the high-speed hammer’s impact and grinding action. In the lower part of the rotor, there is a sieve plate. The particles smaller than the screen hole size in the crushed materials are discharged through the sieve plate. The coarse particles larger than the screen hole size are retained on the sieve plate continue to be hit and ground by the hammer, and finally pass through the sieve plate. discharged from the machine.
